4746
GB
TABLE OF CONTENTS
1. INTRODUCTION 48
2. SAFETYPRECAUTIONS 49
3. INSTALLATION INSTRUCTIONS 51
3.1 Preparing for installation 51
3.2 Fuel 52
3.3 Connecting the gas supply 52
3.4 The chimney 53
3.5 Placement and adjustment of the legs 53
3.6 Placement of the built-in hearth 54
3.7 Setting the burner pressure 55
3.8 Hearth security features 56
3.9 Placement of the wood set 57
4. CLEANING AND MAINTENANCE 58
5. PROBLEMS 59
APPENDIX 1 PARTS LIST 60
APPENDIX 2 TECHNICAL DATA 62
APPENDIX 3 BURNER PRESSURE 64
GB
DESCRIPTION OF THE HEARTH
LEGEND
1. Valve
2. Exhaust Pipe Collar
3. Glass Seal
4. Front
5. Glass Plate
6. Base
7. Ignition/Pilot Light Unit
8. Burner
9. Control Knob
10. Valve Control
11. Air Intake
12. Adjustable Legs
TECHNICAL DATA
Flue gas pipe diameter ø 150 mm
Air intake pipe diameter ø 125 mm
Height 640 mm
Width 700 mm
Depth 365 mm
Exhaust Pipe diameter 150 mm
