Fabral 5V Crimp - Page 19

SKYLIGHT
DETAIL “B”
2"
L
2"
SLOPE
2"
2 1/2"
CUT HERE
FOLD HERE
90 DEGREE
2"
CUT HERE
REMOVE THIS
MATERIAL
Notes:
1. Trim and bend the right side skylight flashing as indicated.
2. Trim the left side in a similar fashion. (Keep in mind the up from the downhill ends.)
SKYLIGHT
DETAIL C
DETAIL B
SLOPE
DETAIL A
SKYLIGHT FLASHING (SIDE)
#14 WOODSCREW 12"O.C
#14 WOODGRIP
WOODSCREW 4"O.C.
TAPE SEALANT
FIELD FORMED
SIDE FLASHING
Notes:
In reference to details A, B, and C.
SKYLIGHT TOP FLASH-
SUGGESTED SHAPE
4
5
8
"
12"
SKYLIGHT BOTTOM FLASH-
SUGGESTED SHAPE
4
3
16
"
4
3
16
"
SKYLIGHT DOWNHILL
#14x 1 1/2" SCREW
12" O.C.
PLYWOOD DECK
#14 MILL POINT
SCREW @ 4" O.C.
CLOSURE W/ BUTYL SEALANT
TOP & BOTTOM
SKYLIGHT BOTTOM FLASH
CHIMNEY FLASHING
