Fabral 5V Crimp - Page 7

Estimating Guide
#14 x 1 Accessory Screws
(_____ft. EAVE x 1/ft) + (_____ft. GABLE x 2/ft) + (_____ft. VALLEY x 3/ft) + (_____ft. SKYLIGHT/CHIMNEY
PERIMETER x 2/ft) = ________ screws
#14 x 1½ Accessory Screws
(_____ft. RIDGE x 2/ft) + (_____ft. SIDEWALL x 2/ft) + (_____ft. ENDWALL x 1/ft) + (____ft. HIP x 3/ft) +
(____ft. TRANSITION x 2/ft) + (____ft. GAMBREL x 2/ft) = ________screws
Sealant Calculations:
¼” x
3
/
16
” x 40’ Rolls Butyl Sealant Tape
(____ft. EAVE x 2.06’) + (____ft. NON-VENTED RIDGE x 4.125’) + (____ft. GABLE) (____ft. SIDEWALL) +
(____ft. ENDWALL x 2.06’) + (____ft. HIP x 4.5’) + (____ft. VALLEY x 4’) + (____ft. TRANSITION x 4.125’) +
(____ft. GAMBREL x 4.125’) = _____ft ÷ 40’/roll = ____ rolls
Closures:
1 x 1 x 13’-2” Sealer Strip
(____ ft. HIP + ____ VALLEY) ÷ 6.5 = ____ pcs.
Outside Closure
(____ ft. NONVENTED RIDGE x 1 pc./ft.) + (____ ft. ENDWALL x .5 pcs./ft.) + (____ ft. TRANSITION x .5
pcs./ft.) + (____ ft. GAMBREL x .5 pcs./ft.) + (____ ft. SKYLIGHT/CHIMNEY x .5 pcs./ft) = _____ pcs.
Inside Closures
(____ ft. EAVE x .5/ft.) + (____ ft. ENDWALL x .5) + (____ ft. TRANSITION x .5) + (____ ft. GAMBREL x
.5)
= _____ pcs.
Profile Vent for Vented Ridge:
____ ft. of VENTED RIDGE ÷ 50 = _________
_____ rolls Profile Vent for 5V
(available in 100’ rolls only)
Touch-Up Paint - 1oz. = _____
Pipe Boots - Gray EPDM:
BASE
DIAMETER
ITEM # PIPE SIZE
MINIMUM
MAXIMUM
7¾ 3 ¼” 5”
10¾ 5 4¼” 7½”
16½ 8 7” 13”
