16
Measuring AC or DC Voltages (Voltmeter)
Set the selector switch to the voltmeter function V.
Place the contact tips in parallel on the circuit to be measured.
Range switching and AC/DC selection are automatic.
In V DC, the display indicates : OL
___
above + 600 V
OL
___
below - 600 V
In V AC, the display indicates : OL above 900 V peak
In V AC, an audible repetitive beeping indicates that the measurement voltage
is greater than the normative safety voltage to assure user protection, that is, 30
V AC (45 V DC or peak) (V-Live function).
Display Range V V V
Measurement 0,20 - 39,99 V 40,0 - 399,9 V 400 - 600 V DC
Range 400 - 900 V AC
Precision 1% ± 5 points 1% ± 2 points 1% ± 2 points
Resolution 10 mV 0,1 V 1 V
Input Impedance MΩ
