Facom 712B - 5.2.3 AC Current Specifications; Further Technical Data; 5.2.4 DC Current Specifications; 5.2.5 Resistance Specifications

31
- Response: Average; calibrated to rms sine wave.
5.2.3 AC Current
- Frequency range: 45Hz~65Hz.
- Max. input current: up to 600A for no more than 60
seconds.
- Response: Average; calibrated to rms sine wave.
NOTE: Only when the current value is greater than 0.2A,
the meter will show its frequency value.
NOTE: When there is voltage or resistance detected in the
AC current shift, the LCD will display «Err».
5.2.4 DC Current
- Max. input current: up to 600A for no more than 60
seconds.
NOTE: When there is voltage or resistance detected in the
AC current shift, the LCD will display «Err».
5.2.5 Resistance
Range Resolution Accuracy
20A 0.01A
±(2.5% of reading + 8 digits)
200A 0.1A
600A 1A
±(3.0% of reading +10 digits)
Range Resolution Accuracy
20A 0.01A
±(2.5% of reading + 8 digits)
200A 0.1A
600A 1A
±(3.0% of reading +10 digits)
Range Resolution Accuracy
2KΩ 0.001KΩ
±(0.8% of reading + 3 digits)
20KΩ 0.01KΩ
200KΩ 0.1KΩ
2MΩ 0.001MΩ
10MΩ 0.01MΩ ±(1.0% of reading + 5 digits)
NU-712B_0618 7 langues.indd 31 22/06/2018 11:50:59
