16
Machines elements
1 : operating trigger with variator
2 : rotational direction switch
3 : LED light switch
4 : LED - Light Emitting Diode
5 : slow / fast speed selector
6 : screwing torque selector
(15 screwing positions + 1 drilling position)
7 : battery release button
8 : battery charge test
9 : access cap to brushes (CL2.CBN1)
10 : charge and alarm indicators
11: instruction manual
SPARE PARTS
B : spare chucks (13 mm: CL2.PM13)
C : spare batteries (19,2 Vd.c: CL2.BA19)
D : charger (CL2.CH919)
E: spare brushes kit (CL2.CBN1)
CL2.P1913D CL2.BA19 CL2.CH1419 NU-CL2.CP1913/0109
809176 809184 809205
Technical specifications
Machine CL2.P1913D
Chuck capacity 13 mm
Max steel drilling 13 mm
Max wood drilling 40 mm
No-load motor voltage 19,2 Vd.c
No-load speed (slow) 0 - 350 rev/min
No-load speed (fast) 0 - 120 rev/min
Torque setting 15 positions + drilling
Max torque 50 Nm
Weight, battery excl 1,5 kg
