18
FACOM ACCESSORIES
Drill bits
Ground twist drills: reference 222A.T
- for steel, stainless steel, gray cast-iron, and aluminium alloy.
- dimensions available: from 1 to 13 mm by 1/2 mm
- available itemised or in sets:
- 222A.TJ19: 19 drills from 1 to 10 mm
- 222A.TJ 25: 25 drills from 1 to 13 mm
Metal drills: reference 222
- for steel
- dimensions available: from 1 to 13 mm by 1/2 mm
- available itemised or in sets:
- 222.TLJ10: 10 drills from 3 to 10 mm
- 222.J19: 19 drills from 1 to 10 mm
- 222 .J25: 25 drills from 1 to 13 mm
Bit holders
- for screwing bits with 6.35 mm (1/4’) hexagon socket heads
- EF.6P6: magnetic bit holder with lock-ring (L:77 mm)
- EF.6P4: magnetic bit holder with spring clip (L: 75 mm)
- EF.6P1: short bit holder with spring clip (L: 57 mm)
Screwing bits
- full range of screwing bits
(all profiles and dimensions), different grades (standard, extra-hard or titanium).
Screwing blades
- full range of screwing blades 50, 70, and 90 mm long
(all profiles and dimensions), different grades (standard, extra-hard or titanium).
Screwing sockets
- range of standard or magnetic screwing sockets from 5.5 to 13 mm.
Socket holders
- EF.6R: 1/4’’ bit-locking plunger (length 50 mm)
- EF.6RL: 1/4’’ bit-locking plunger (length 100 mm)
- EF.6J: 3/8’’ bit-locking plunger (length 50 mm)
- EF.6JL: 3/8’’ bit-locking plunger (length 100 mm)
Changing the chuck:
1) Fully open the chuck and unscrew the fastening screw located at its centre (caution: reversed unscrewing direction).
2) Position the speed selector to «low», the torque selector in the drilling position and the rotation direction reverser in the unscrew position.
3) According to your chuck model, insert and lock the appropriate disassembly wrench (A) or lock the sleeve firmly (B).
Lock the machine firmly and pull the trigger to unscrew the chuck.
222A.T
222.J19
222A.TJ32
EF.6P6EF.6P4EF.6P1
LOW
STOP
B
A
STOP
1 2 3
