FC-MICRO-HD-OP-EN - 9 -
1. SOLUTION OUTPUT - Indicates the level of solution that is being dispensed when in operation
2. TECHNICAL / MANAGER SETUP - Access ‘Error Code History’ and Manager Programming
3. PROGRAMMED ZONES - Switch between preset solution and downpressure settings for varying applications
4. HOUR METERS - Displays all of the hour meters of the machine: Key Switch, Transport, Scrub Motors, and Vacuum
Motor
5. DOWN PRESSURE OUTPUT - Indicates the level of downpressure that is being applied to the fl oor surface
6. BATTERY GAUGE - Indicates the level of battery charge available
7. ACTIVE VOLT & AMP DRAW - Indicates the live DC Volts (under battery gauge) and Amp draw (under systems)
when machine is running
8. ACTIVE SYSTEM MACHINE DISPLAY - Indicates which systems of the equipment currently has power
9. OPERATION MODE SELECTOR - Cycle through and select which operation mode you would like to work in
TOUCH SCREEN (OPTIONAL)
3
#1 NAME
SUDSSUDS
3
#1
SUDSSUDS
24.9
22.5 34.2
1
6
879
234 5
