CHECKS and INSPECTION AFTER INSTALLATION
Date:
the gate opener
Faults
The gate will not move
- No programming performed
- One or more NC contacts open
- Burnt fuses
- Torque too low
- Photocells not aligned or disturbed
- Perform programming (pg.34)
- Check all NC contacts
(green LEDs must all be on)
- Check conditions of all fuses
- Enable the Torque Trimmer to increase it
- Align photocells and verify conditions
LED lamp on casing o
- No 230 V power
- 5 A line fuse burnt
- 6,3 A fuse for 24 V burnt
- Bart 350 unlocked
- Bart 350 unlocked with the unlock
handle accidentally removed
- Check the line and all fuses
- Put the handle in lock position (pg.37) and lock
the round sticker must be in vertical position (pg.36)
LED lamp on casing slowly
flashing BLUE
- In the 5 previous manoeuvres, the
gate showing a fault was not able to
automatically close due to an obstacle
that would not allow correct movement of
the gate itself.
- Remove obstacles and give an opening/closing command
- Increase torque using Trimmers
LED lamp on casing
alternatively flashing BLUE-
ORANGE
- Photocell malfunction on DSA control
carried out before movement
- Re-align Photocells
- Disconnect power to photocells for a few seconds
- Power supply of the photocells on DSA control is to be
connected to terminals 13-14
- Detects the continuous presence of
an obstacle or possible friction during
movement
- Photocells not aligned
- Remove obstacles and give an
opening/closing command
- Increase torque using Trimmers
- Align photocells
Cause Operations
DECLARATION OF CONFORMITY
T
O RESET AND RESTORE DEFAULT MODES
MALFUNCTION CAUSES AND NECESSARY OPERATIONS
To ensure the safety and long-lasting operation of t
he gate, check that:
2) the ground stops are stable and will not yield under the action of motorised gates
3) the photocells are correctly aligned to one another (green LEDS L1 and L2 on)
4) all green LEDs on Elpro 35M and Elpro 35S boards are on
If programming has been performed, it is advisable
right and left installation of the Bart 350 Master). Then, disconnect electrical power for 4-5 seconds and, once power
has been restored, give an opening pulse to the system.
The “LED” device on the protective casing is a xed light BLUE when the automatism is working properly. It ashes or becomes ORANGE
in the presence of any electrical system faults.
Manufacturer: A
ddress:
The Responsible Manager
e
c
canica
canica
F
F
a
a
d
in
in
i
s
.n.
c
.
R
esp
o
o
ns
ns
i
i
ble ble
M
M
a
a
n
n
n
ag
ag
e
r
DECLARES UNDER ITS OWN RESPONSIBILITY THAT:
Model: Electro-mechanical opener for swinging gates BART 350 IS IN COMPLIANCE WITH THE NORMS 2006/42/CE
Bart 350 is to be sold and installed as a comprehensive “Automatic System”, including the accessories and components as recommended by the
Manufacturing Company. In observance of the current directives, any automation is to be regarded as a “machine”. Therefore it is required that all the
applicable safety norms are strictly complied with by installation agents, who are also required to issue a Declaration of Conformity.
The manufacturing company is not liable for incorrect applications or misuse of its products
that are declared to be produced in compliance with the following norms:
- Analysis of the risk and actions to cure them: EN 12445 and EN 12453
- Low Voltage Directive: 2006/95 CE
- Electro-magnetic Compatibility Directive: 2004/108/CE
In order to certify the product the Manufacturer declares under his own responsibility
the compliance with the PRODUCT regulations under the NORMS EN 13241-1
Via Mantova, 177/A - 37053 Cerea (VR) Italy
Tel.+39 0442 330422 r.a. - Fax +39 0442 331054
e-mail: info@fadini.net - www.fadini.net
10 / 01 / 2014
The gate starts moving,
then it stops or reverses
