- 40 -
English
INTRODUCTION
This operator is designed for a specic scope of applications as
indicated in this manual, including safety, control and signaling
accessories as minimum required with FADINI equipment. □
Any applications not explicitly included in this manual may
cause operation problems or damages to properties and people.
□ Meccanica Fadini snc is not liable for damages caused by the
incorrect use of the equipment, or for applications not included
in this manual or for malfunctioning resulting from the use of
materials or accessories not recommended by the manufacturer.
□ The manufacturer reserves the right to make changes to its
products without prior notice. □ All that is not explicitly
indicated in this manual is to be considered not allowed.
BEFORE INSTALLATION
Before commencing operator installation assess the suitability
of the access, its general condition and the structure. □ Make
sure that there is no risk of impact, crushing, shearing,
conveying, cutting, entangling and lifting situations, which may
prejudice people safety. □ Do not install near any source of heat
and avoid contacts with ammable substances. □ Keep all the
accessories able to turn on the operator (transmitters, proximity
readers, key-switches, etc) out of the reach of the children. □
Transit trough the access only with stationary operator. □ Do not
allow children and/or people to stand in the proximity of a
working operator. □ To ensure safety in the whole movement
area of a gate it is advisable to install photocells, sensitive edges,
magnetic loops and detectors. □ Use yellow-black strips or
proper signals to identify dangerous spots. □ Before cleaning
and maintenance operations, disconnect the appliance from the
mains by switching o the master switch. □ If removing the
actuator, do not cut the electric wires, but disconnect them from
theterminal box by loosening the screws inside the junction box.
INSTALLATION
All installation operations must be performed by a qualied
technician, in observance of the Machinery Directive
2006/42/CE and safety regulations EN 12453 - EN 12445. □ Verify
the presence of a thermal-magnetic circuit breaker 0,03 A - 230 V
- 50 Hz upstream the installation. □ Use appropriate objects to
test the correct functionality of the safety accessories, such as
photocells, sensitive edges, etc. □ Carry out a risk analysis by
means of appropriate instruments measuring the crushing and
impact force of the main opening and closing edge in
compliance with EN 12445. □ Identify the appropriate solution
necessary to eliminate and reduce such risks. □ In case where the
gate to automate is equipped with a pedestrian entrance, it is
appropriate to prepare the system in such a way to prohibit the
operation of the engine when the pedestrian entrance is used. □
Apply safety nameplates with CE marking on the gate warning
about the presence of an automated installation. □ The installer
must inform and instruct the end user about the proper use of
the system by releasing him a technical dossier, including: layout
and components of the installation, risk analysis, verication of
safety accessories, verication of impact forces and reporting of
residual risks.
INFORMATION FOR END-USERS
The end-user is required to read carefully and to receive
information concerning only the operation of the installation so
that he becomes himself responsible for the correct use of it. □
The end-user shall establish a written maintenance contract
with the installer/maintenance technician (on -call). □ Any
maintenance operation must be done by qualied technicians.
□ Keep these instructions carefully.
WARNINGS FOR THE CORRECT OPERATION OF THE
INSTALLATION
For optimum performance of system over time according to
safety regulations, it is necessary to perform proper
maintenance and monitoring of the entire installation: the
automation, the electronic equipment and the cables
connected to these. □ The entire installation must be carried out
by qualied technical personnel, lling in the Maintenance
Manual indicated in the Safety Regulation Book (to be
requested or downloaded from the site
www.fadini.net/supporto/downloads).
□ Operator: maintenance inspection at least every 6 months,
while for the electronic equipment and safety systems an
inspection at least once every month is required. □ The
manufacturer, Meccanica Fadini snc, is not responsible for
non-observance of good installation practice and incorrect
maintenance of the installation.
DISPOSAL OF MATERIAL
Dispose properly of the packaging materials such as cardboard,
nylon, polystyrene etc. through specializing companies (after
verication of the regulations in force at the place of installation
in the eld of waste disposal). Disposal of electrical and
electronic materials: to remove and dispose through
specializing companies, as per Directive 2003/108/CE.
Disposal of substances hazardous for the environment is
prohibited.
GENERAL WARNINGS FOR PEOPLE SAFETY
