Ca = Heizkessel
DV1 = Volumenometer 1
DV2 = Volumenometer 2
Eac = Magnetventil Heißwasser
Em = Magnetventil Milchabgabe
Evc = Magnetventil Wassertank
Fi = Entstörungsfilter
G1 = Magnetventil Kaffeeabgabe 1
G2 = Magnetventil Kaffeeabgabe 2
IG = Hauptschalter
Im = Schalter Milchabgabe
J = Jumper
Lc = Kontrolleuchte ‘Auffüllung Heizkessel’
Lma = Kontrolleuchte ‘Maschine eingeschaltet’
MP = Pumpenmotor
PL1c1 = Schalter und Kontrolleuchte Abgabe 1
Espressokaffee Einheit 1
PL1c2 = Schalter und Kontrolleuchte Abgabe 1
Espressokaffee Einheit 2
PL1l1 = Schalter und Kontrolleuchte Abgabe 1
normaler Kaffee Einheit 1
PL1l2 = Schalter und Kontrolleuchte Abgabe 1
normaler Kaffee Einheit 2
PL2c2 = Schalter und Kontrolleuchte Abgabe 2
normale Kaffees Einheit 2
PL2l2 = Schalter und Kontrolleuchte Abgabe 2
normale Kaffees Einheit 2
PLac = Schalter und Kontrolleuchte Heißwasserabgabe
PLc = Schalter und Kontrolleuchte Cappuccino-Abgabe
PLl = Schalter und Kontrolleuchte Milchabgabe
PR = Druckwächter
Ps1 = START-STOPP-Schalter Einheit 1
Ps2 = START-STOPP-Schalter Einheit 2
Psac = STOPP-Schalter Wasserabgabe und Schalter
Programmierung
Ptc = Ptc
RC = Heizelement Heizkessel
Rec = Relais Heizkessel
Rmp = Relais Pumpenmotor
rmp = Kontakt Relais Pumpenmotor
SL = Fühler Wasserstand Heizkessel
SM = Massenfühler
TC = Sicherheitsthermostat Heizkessel
TR = Umwandler
Y... = Steckverbinder
Ca = Caldera
DV1 = Contador volumétrico 1
DV2 = Contador volumétrico2
Eac = Electroválvula agua caliente
Em = Electroválvula Leche
Evc = Electroválvula carga caldera
Fi = Filtros antiperturbaciones
G1 = Electroválvula café 1
G2 = Electroválvula café 2
IG = Interruptor general
Im = Interruptor leche
J = Jumper
Lc = Indicador luminoso carga caldera
Lma = Indicador luminoso máquina encendida
MP = Motor bomba
PL1c1 = Botón e indicador luminoso 1 café fuerte
gr. 1
PL1c2 = Botón e indicador luminoso 1 café fuerte
gr. 2
PL1l1 = Botón e indicador luminoso 1 café suave
gr. 1
PL1l2 = Botón e indicador luminoso 1 café suave
gr. 2
PL2c2 = Botón e indicador luminoso 2 cafés fuertes
gr. 2
PL2l2 = Botón e indicador luminoso 2 cafés suaves
gr. 2
PLac = Botón e indicador luminoso agua caliente
PLc = Botón e indicador luminoso capuchino
PLl = Botón e indicador luminoso leche
PR = Presostato
Ps1 = Botón START-STOP grupo 1
Ps2 = Botón STAR-STOP grupo 2
Psac = Botón STOP agua caliente y Programación
Ptc = Ptc
RC = Resistencia caldera
Rec = Relé caldera
Rmp = Relé motor bomba
rmp = Contacto relé motor bomba
SL = Sonda nivel caldera
SM = Sonda de masa
TC = Termostato de seguridad caldera
TR = Transformador
Y... = Conector
Ca = Caldeira
DV1 = Contador volumétrico 1
DV2 = Contador volumétrico 2
Eac = Válvula de solenóide água quente
Em = Válvula de solenóide leite
Evc = Válvula de solenóide carga caldeira
Fi = Filtros anti-distúrbio
G1 = Válvula de solenóide café 1
G2 = Válvula de solenóide café 2
IG = Interruptor geral
Im = Interruptor leite
J = Jumper
Lc = Led carregamento caldeira
Lma = Led máquina acesa
MP = Motor bomba
PL1c1 = Botão e led 1 café curto gr. 1
PL1c2 = Botão e led 1 café curto gr. 2
PL1l1 = Botão e led 1 café longo gr. 1
PL1l2 = Botão e led café longo gr. 2
PL2c2 = Botão e led 2 cafés curtos gr. 2
PL2l2 = Botão e led 2 cafés longos gr. 2
PLac = Botão e led água quente
PLc = Botão e led garoto (cappuccino)
PLl = Botão e led leite
PR = Pressóstato
Ps1 = Botão START-STOP gr. 1
Ps2 = Botão START-STOP gr. 2
Psac = Botão STOP água quente e Programa
Ptc = Ptc
RC = Resistência caldeira
Rec = Relè caldeira
Rmp = Relè motor bomba
rmp = Contacto relè motor bomba
SL = Sonda nível caldeira
SM = Sonda de massa
TC = Termóstato de segurança caldeira
TR = Transformador
Y... = Conector
P
LEGENDA dt2
E
LEYENDA dt2
D
LEGENDE dt2
F
LEGENDE dt2
Ca = Chaudière
DV1 = Compteur volumétrique 1
DV2 = Compteur volumétrique 2
Eac = Electrovalve eau chaude
Em = Electrovalve Milk
Evc = Electrovalve charge chaudière
Fi = Filtres anti-dérangement
G1 = Electrovalve café 1
G2 = Electrovalve café 2
IG = Interrupteur général
Im = Interrupteur Milk
J = Jumper
Lc = Led chargement chaudière
Lma = Led machine allumée
MP = Moteur pompe
PL1c1 = Touche et led 1 café court gr. 1
PL1c2 = Touche et led 1 café court gr. 2
PL1l1 = Touche et led 1 café long gr. 1
PL1l2 = Touche et led 1 café long gr. 2
PL2c2 = Touche et led 2 cafés courts gr. 2
PL2l2 = Touche et led 2 cafés longs gr. 2
PLac = Touche et led eau chaude
PLc = Touche et led cappuccino
PLl = Touche et led lait
PR = Presostat
Ps1 = Touche START-STOP gr.1
Ps2 = Touche START-STOP gr. 2
Psac = Touche STOP eau chaude et programme
Ptc = Ptc
RC = Résistance chaudière
Rec = Relais chaudière
Rmp = Relais moteur pompe
rmp = Contact relais moteur pompe
SL = Sonde niveau chaudière
SM = Sonde de masse
TC = Thermostat de sécurité chaudière
TR = Transformateur
Y... = Connecteur
LEGEND dt2
GB
Ca = Boiler
DV1 = Volumetric meter 1
DV2 = Volumetric meter 2
Eac = Hot water solenoid valve
Em = Milk solenoid valve
Evc = Boiler supply solenoid valve
Fi = Inteference filter (suppressor)
G1 = Coffee solenoid valve 1
G2 = Coffee solenoid valve 2
IG = Main switch
Im = Milk switch
J = Jumper
Lc = Led: boiler refilling
Lma = Led: machine ON
MP = Pump motor
PL1c1 = Push button and led: 1 short coffee
PL1c2 = Push button and led: 1 short coffee gr. 2
PL1l1 = Push button and led: 1 long coffee
PL1l2 = Push button and led: 1 long coffee gr. 2
PL2c2 = Push button and led: 2 short coffee gr. 2
PL2l2 = Push button and led: 2 long coffee gr. 2
PLac = Push button and led: hot water
PLc = Push button and led: cappuccino
PLl = Push button and led: milk
PR = Pressure sensor
Ps1 = Push button: START-STOP gr. 1
Ps2 = Push button: START-STOP gr. 2
Psac = Push button: STOP hot water and Program
Ptc = Ptc
RC = Service boiler resistance
Rec = Service boiler relay
rmp = Pump motor relay contact
Rmp = Pump motor relay
SL = Boiler level probe
SM = Mass probe
TC = Boiler supply security thermostat
TR = Transformer
Y... = Connectors
Ca = Caldaia
DV1 = Contatore volumetrico 1
DV2 = Contatore volumetrico 2
Eac = Elettrovalvola acqua calda
Em = Elettrovalvola Milk
Evc = Elettrovalvola carico caldaia
Fi = Filtro antidisturbo
G1 = Elettrovalvola caffè 1
G2 = Elettrovalvola caffè 2
IG = Interruttore generale
Im = Interruttore Milk
J = Jumper
Lc = Led caricamento caldaia
Lma = Led macchina accesa
MP = Motore pompa
PL1c1 = Pulsante e led 1 caffè corto gr. 1
PL1c2 = Pulsante e led 1 caffè corto gr. 2
PL1l1 = Pulsante e led 1 caffè lungo gr. 1
PL1l2 = Pulsante e led 1 caffè lungo gr. 2
PL2c2 = Pulsante e led 2 caffè corti gr. 2
PL2l2 = Pulsante e led 2 caffè lunghi gr. 2
PLac = Pulsante e led acqua calda
PLc = Pulsante e led cappuccino
PLl = Pulsante e led latte
PR = Pressostato
Ps1 = Pulsante START-STOP gr. 1
Ps2 = Pulsante START-STOP gr. 2
Psac = Pulsante STOP acqua calda e Program
Ptc = Ptc
RC = Resistenza caldaia
Rec = Relè caldaia
rmp = Contatto relè motore pompa
Rmp = Relè motore pompa
SL = Sonda livello caldaia
SM = Sonda di massa
TC = Termostato di sicurezza caldaia
TR = Trasformatore
Y... = Connettore
LEGENDA dt2
