ERRORS FOUND IN THE INSTALLATION MANUAL (REF. 9707)
Appendix "F" page 10. P621(7)
It is wrong, it should say:
P621(7) The M06 function executes the M19 function (0=Yes, 1=No)
Appendix "G" page 20. P621(7)
It is wrong, it should say:
P621(7) The M06 function executes the M19 function (0=Yes, 1=No)
MODIFICATIONS TO THE INSTALLATION MANUAL (REF. 9707)
Comparison table xii. Technical description. Inputs/Outputs.
Feedback inputs for rotary axes, it should say: W (GP), W (M), W (MG), W V (MS)
Comparison table xii. Technical description. Axis control.
GP M MG MS
Electronic threading. It should say x x x
Comparison table xii. Technical description. Others. Add fields
GP M MG MS
Open loop motors without servodrives................................x
Laser machines...................................................................... x x x
JIG Grinders........................................................................... x x x
Section 3.3.3 (chapter 3 page 15). P612(6). Another example:
Having a Fagor electronic handwheel (25 lines/turn) set as follows:
P612(3) = 0 Millimeters P612(4) = 0 and P612(5) = 0 Resolution: 0.001 mm.
P612(6) = 0 Multiplication factor x4
Depending on the position of the MFO switch (Manual Feedrate Override) the selected axis will move:
Position 1 1 x 25 x 4 = 0.100 mm per turn
Position 10 10 x 25 x 4 = 1.000 mm per turn
Position 100 100 x 25 x 4 = 10.000 mm per turn
MODIFICATIONS TO THE PROGRAMMING MANUAL (REF. 9701)
Section 6.30.4 (page 128). G76 Automatic block generation
If the new program to be created is to be sent to a PC (G76 N), the DNC communication must be enabled and, at
the PC, the "program management" "Digitizing Reception" option must be selected.
If it is not, the CNC will issue error 56.
