1.4 Characteristics
HDMI
Encoding
Section
Video
Encoding
H.264
MP@L 3.0/3.1/4.0
Interface HDMI*1
Input Output
Resolution
480i@59.94/60FPS 480p@30FPS
576i@50FPS 576p@25FPS
720p@50/59.94/60FPS 720p@50/59.94/60FPS
1080i@50FPS 1080p@25FPS
1080i@59.94/60FPS 1080p@30FPS
1080p@59.94/60FPS 1080p@30FPS
Aspect Ratio 16:9, 5:4
Bit rate 1.000~18.000 Mbps
Audio
Encoding MPEGI layer 2, MPEG-2 AAC
Sample rate 48KHz
Bit rate 64, 96,128, 192, 256, 320kbps
DVB-T Modulator Section
S
tandard
DVB
-
T COFDM
Bandwidth 6M, 7M, 8M
Constellation QPSK, 16QAM, 64QAM,
Code rate 1/2, 2/3, 3/4, 5/6, 7/8.
Guard Interval 1/32, 1/16, 1/8, 1/4
Transmission Mode: 2K, 8K
MER ≥32dB
RF frequency 142.5~858 MHz, 1KHz step
RF output level -14 ~ +6dBm (94 ~ 114 dBµV), 0.1dB step
System
Management LCD + Keyboard
Language English
LCN Insertion Yes
Upgrade USB
General
Power supply DC 12V
Packing dimensions 183*146*204mm
Weight < 1kg
Operation Temperature 0 ~ 45
o
C
2. Installation Guide and Safety Instructions
2.1 Safety Instructions
WARNING: To prevent fire or electrical shock, do not expose the device to rain or moisture.
The encoder modulator is powered with a voltage of 12V DC. The power supply voltage
must not exceed the recommended voltage, which otherwise may cause irreparable damage
to the device and the invalidation of the warranty. Therefore:
