PAGE 7
REACH-INS OPERATIONAL SERVICE MANUAL / Rev.JUN. 2015
Outside cabinet:
Be sure that the unit has access to ample air to breathe. Avoid hot corners and locations near stoves
and ovens. It is recommended the unit be installed no closer than 3” from any wall. The place where
the refrigerator is placed must be open and clean. This will reduce the amount of debris and dirt on
the condenser fan and coil.
3.3 DATA PLATE
The data plate is located inside the cabinet, near the top front, left corner. Under no circumstances
should the data plate be removed from the unit. The data plate is essential to identify the particular
features of your machine and it is of great benefit to installers, operators, and maintenance
personnel. It is recommended that, in the event the data plate is removed, you copy down the
essential information in this manual for reference before installation. Removal of data plate will void
the warranty.
3.4 INSTALLATION OF CASTORS OR OPTIONAL LEGS
To obtain maximum strength and stability of the unit, be sure that castors are secure and unit is level.
Inside the unit you will find a Castor kit which includes: four castor wheels, leveling shims, and
assembly tool.
Installation of castors:
Cut the 4 straps that hold the refrigerator to the pallet.
Model
Electrical
Refrigerant Type
SERIAL NUMBER FOR
THE EQUIPMENT
(8 digits and ends in
“M”)
