Fairphone 5 - Page 7

Board to
Board
Connector
BM23PF0.8-
20DP-0.35V
Tohoku
Hirose
Electric Co.
Voltage 30 V AC/DC
Signal contact 0.3 A
Power Contact 5.0 A
Operating Temperature: -55 ℃ to 85 ℃
Storage Temperature: -10 ℃ to 60 ℃
Board to
Board
Connector
BM24-20DP
/2-0.35V
Tohoku
Hirose
Electric Co.
Voltage 30 V AC/DC
Signal contact 0.25 A
Power Contact 5.0 A
Operating Temperature: -40 ℃ to 85 ℃
Storage Temperature: -10 ℃ to 60 ℃
Speaker Top
SLS1012A
AAC
Dimensions: 10 x 12 x 2.8 mm
Impedance: 7 Ω @ 2 kHz Input
DC Resistance: 6 Ω
50 mW Rated Power
Operating Temperature: -20 ℃ to +70 ℃
Storage Temperature: -40 ℃ to 85 ℃
Speaker
Bottom
SLS1115D-01
AAC
Dimensions: 11 x 15 x 2.35 mm
8 Ω @ 2 kHz, 1 Vrms Input
1 W Rated Noise (1.5W Max) in 0.7cc
200-20 kHz Frequency range
Operating Temperature: -20 ℃ to +70 ℃
Storage Temperature: -40 ℃ to 85 ℃
Microphone
SM0103B-R
S421-M02
AAC
Sensitivity: -42 dB
Output Impedance: 450 Ω
Supply Voltage: 2.75V to 3.6 V
Rated Current: 100uA
S/N Ratio: 64dB
Power Supply Rejection -95dBV
Load Resistor 5 kΩ
Operating Temperature: -40 to +85 ℃
Soldering Information:
Preheat 150-180℃ for a maximum of 120 secs.
Soldering Above 220℃ for a maximum of 90 secs.
Peak 260℃ for a maximum of 30 seconds.
Do not reflow more than 3 times.
