21
GP1 Chrono
3.2- ESQUEMA FUENTE DE ALIMENTACIÓN · POWER SUPPLY WIRING DIAGRAM .
12V
12VA
X3
X1
X2
GND
+12V
100K
100K
100K
7805
1000
10
+5V
3
2
1
BROWN
BLACK
BLUE
C3
M
MOTOR
POWER
YELLOW-GREEN
MOTOR
THERMIC
100 ?
1/2 W
470 ?
1/4 W
MOC 3021
100K
TIMER CONTROLLER
SOUND GENERATOR
80mA
FUSE
VARIS
275V
*
DEPENDING ON MACHINE POWER
POWER THERMIC MOTOR
110V
220V
240V
2A (c.7763)
5A (c.2644)
3A (c.2643)
*
