8
FOR BACK DUCTED
POSITION
TOP
DUCTED
POSITION
2
3
1
ATTENTION!
ONLY ON
MILANO + DEEP
3
FOR BACK DUCTED
POSITION
TOP
DUCTED
POSITION
2
3
1
ATTENTION!
ONLY ON
MILANO + DEEP
3
x4
CAUTION
CAUTION
10 ÷ 28 mm
5 5a
4
STEP 4:
You screw the blocking devices.
STEP 5:
Connect the hood outlet (in the top or back ducted position)
to 150mm ducting leading to an external output.
