FALMEC nube - MOTOR ON HOOD INSTALLATION: MOTOR AND FLANGE ATTACHMENT; MOTOR AND FLANGE ATTACHMENT

10
INLET
1 2
3
Remove the flange from the hood (1) and the motor (2). If the air outlet is upward, see (3).
For other directions, see (4) and (5).
MOTOR ON HOOD INSTALLATION
