FALMEC nube - CONVEYOR KIT & REMOTE MOTOR INSTALLATION: BRACKET FIXING; BRACKET FIXING TO RECTANGULAR CONNECTION

18
120 mm
AIR
AIR
3
4
2
2
V2 (x4)
V1 (x8)
120 mm
3
V1 (x8)
4
V2 (x4)
2
1
Remove the flange from the hood (1). Fixing the brackets onto the rectangular connection
(2).
INSTALLATION WITH CONVEYOR KIT AND REMOTE MOTOR
