FALMEC POLAR User Manual

16
A
2. CHARCOAL FILTERS
To replace the charcoal filters, proceed as follows: remove the metal filters
as described above. The two filters located at the ends of the motor can
now be easily accessed.
To install the new fi lters see picture.
To order new filters, use the coupon enclosed with this booklet or provided
by the distributor.
LIGHTING ASSEMBLY AND REPLACEMENT
I
SPOTLIGHT
How to replace the dichroic lamp:
a) Check that the equipment is disconnected from the power supply.
b) Remove the lamp with the help of a screwdriver (see figure).
c) Replace the lamp with a similar one (dichroic, max 20 W, 12 Volt).
Dicroic Lamp
MAINTENANCE AND CLEANING
L
Constant maintenance ensures the correct operation and efficiency of the ap-
pliance over time. Special attention should be paid to the metal grease-trap-
ping filters and the charcoal filters. Frequent cleaning of the filters and their
supports will ensure that fats and grease do not accumulate on the range
hood, with the consequent risk of fire.

FALMEC POLAR Specifications

General

Pressure (Pa)	420
Number of speeds	4
Type of extraction	-
Noise level (low speed)	50 dB
Maximum extraction power	800 m³/h
Noise level (high speed)	63 dB
Noise level (medium speed)	56 dB
Minimum distance from electric hob	600 mm
Type	Wall-mounted
Control type	Buttons
Product color	White
Motor included	Yes
Built-in display	No
Exhaust location	Top
Housing material	Steel
Exhaust connection diameter	150 mm
Bulb type	LED
Bulb power	1.2 W
Number of bulbs	4 bulb(s)
Grease filter type	Charcoal
Motor power	243 W

Weight and Dimensions

Depth	430 mm
Width	350 mm
Weight	24000 g
Height (max)	915 mm
