Components and functions:
Plug and connection assignment:
Confi guration 6,35 mm mono jack:
Ground, shielding
Diagram 1
Press 1x
Start recording mode (red LED).
Start playback (LED green).
Press 2x Pause loop playback.
Hold for 2 seconds Undo/Redo function, delete stored loop.
Diagram 2
LED red Recording mode On.
LED green Playback mode On.
LED fl ashes green Already 1 loop in memory.
