4. Using the ITM-A
4.1 Setting the knob
The knob on the front of the ITM-A is used to set the ATM-unit to:
• Automatic (A) or
• Manual (M)
4.2 Display (option)
A key on the front panel is available as an option.
If this key is pressed, the following will be displayed alternately:
• Temperature
Own temperature measurement of the ITM-A, without offsets of
the control computer, without averaging of other values (only
when controlled via the IO-network).
• Control and measured value ventilation
The control value is the control of the ITM-
A (ventilation position or
position of analogue output) measured value based on the
calibration value in the ITM-A.
If the key is not used, then the temperature readout will be displayed again, 30 seconds after the key was used for
the last time.
If the rotary knob is set to manual (M), the display will flash.
When type of control is CentralFlow, only the vortex damper can be controlled manually.
When type of control is ProFlow/NatuFlow, both I-fan and vortex damper can be controlled manually.
