7. Technical specifications
Power supply
Mains voltage
230Vac (-10%, +10%)
Mains frequency
50/60Hz
Maximum power consumption
5VA
Fuse electronics
see connection diagram
Inputs
Analog In
Voltage
0-10Vdc
Temperature sensor type S7
-9.9°C to +99.9°C
DSR-feedback
4 pulses per revolution
max. frequency: 200Hz
Knob
Adjust ventilation between 0 – 100%
Outputs
Power outage relay
30Vac/60Vdc, max. 2A
Relay 2×
30Vac/60Vdc, max. 2A
Analog out
10-0Vdc
Housing
Plastic housing with screw-on lid
IP54
Dimensions (l×w×h)
300×240×140mm
Weight (unpacked)
2.2kg
Ambient climate
Operating temperature range
0
°
C to +40
°
C
Storage temperature range
–10
°
C to 50
°
C
Relative humidity
< 95%, uncondensed
Options
Display with key on front panel
Available as an option
