Method 99% adjustment
1. Set the analog output of the controller to 99%. Check the voltage, this should be between 0.1 and 1V (with a
0-10V control this is between is 9V and 10V).
2. Turn the knob on the front to its maximum position. The red led (L1) flashes: longer period on, briefly off. The
green led (L2) is off. This means that the 99% will be adjusted.
3. Confirm the 99% adjustment by pressing the knob. The green led (L2) flashes.
4. The ITM-A has completed adjustment after five seconds. The status of the adjustment can now be shown.
- Green led on : Adjustment successful.
- Red led on : Adjustment unsuccessful. The most common cause is that the ITM-A has
measured none or too few pulses. Check the DSR-feedback sensor and
repeat the adjustment procedure.
After adjustment set dipswitches 9 and 10 to ON and the knob to A.
