USER MANUAL FOR FT TOWERS 27
Figure 78
Unlock the security brake of the aluminium
carrier
Figure 79
Place the accessory in the calculated position.
Figure 80
Join the truss system to the tower.
Figure 81
Unlock the mast safety system. Operate the
winch handle to raise the load.
IMPORTANT ¡!! FOR THIS PURPOSE, USE
ONLY MANUAL HOISTS
