Description and Technical Data
1. REMOVING THE PACKAGING
Before shipping, the bicycle is protected with
bubble wrapping and packaged in order to
ensure that if reaches you in perfect condition.
Remove the packaging carefully and dispose
of it in compliance with the locally applicable
regulations.
The items of the packaging
(plastic bags, polystyrene,
straps, etc.) must not be left
within the reach of children.
2. IDENTIFICATION PLATE
Each bicycle is equipped with an identication
plate positioned in the rear part of the chassis
(g. 1).
Please communicate the serial number indicated
on the plate whenever you ask for assistance or to
order spare parts.
3. EXTERNAL DIMENSIONS
(M size)
(Figures “2“, “3“ and “4“)
ILLUSTRATIONS
The illustrations are grouped on the initial pages of the manual
4. STANDARD EQUIPMENT
Once you have removed your bicycle from its
packaging, check that the following compo-
nents are present
(to identify the components, refer to the g-
ures “5“, “6“, “7“ and “8“):
- Complete bicycle
pos. 29 Right hand pedal
pos. 35 Left hand pedal
pos. 13 Battery charger
pos. 15 Battery charger power supply cable
pos. 10 User and maintenance manual
pos. 43 “Safety recommendations” manual
5. IDENTIFYING THE BICYCLE
COMPONENTS
(Figures “5“, “6“, “7“ and “8“)
1 Front tyre
1a Tyre valve
2 Front brake lever
3 Rear brake lever
4 Left hand grip
5 Function selector buttons
6 Handlebars
7 Control panel - display
8 User mode selector buttons
9 Right hand grip
10 User and maintenance handbook
11 Battery LED
12 Li-Ion rechargeable battery pack
13 Battery charger
14 Rear hub axle
15 Battery charger power supply cable
16 Sprocket set
17 Saddle tube
18 Saddle
19 Battery pack support
20 Handlebar tube
21 Rear tyre
22 Wheel cover strip
23 Gear change unit
24 Chain
> > > > >
