Description and Technical Data
MODEL
FAT INTEGRA XF2 INTEGRA LIVING
Motor Brose series S 36V 250 W
Battery Fantic Integra 630 wh
Display Multifunction LCD
Chassis Aluminium S/M/L
Suspension fork
Rockshox Bluto
120mm
RockShox Recon RL29
120mm
Suntour XCR34
100mm
Gear change unit Sram NX 11V Sram GX 10V
Cranks Aluminium 170mm
Sprockets 11-42 th 11-36 th
Front gear 32th 38th
Chain KMC 11V-e
Brake system Sram Level
Front disk 200mm 180mm
Rear disk 180mm 160mm
Tyres
Schwalbe Jumbo Jim
26x4 “
Schwalbe Smart Sam
F 29x2,25 R 27,5x2,6
Swchalbe Super Moto
x 27.5x2.8
Front wheel
26” 150mm 32sp
pin 15mm
29” 110mm 32sp
pin 15mm
27,5”110 mm 32sp
pin 15mm
Rear wheel
26” 197mm 32 sp
pin 12mm
27,5” 148mm 32 sp
pin 12mm
27,5 “ 148mm 32 SP
pin 12mm
Handlebar Fantic 740mm FSA 720mm
Handlebar mount Fantic 60mm FSA 100mm
Headset Semi integrated 1”1/8 - 1,5”
Max load 120kg
Working temp 0/45 °C
25 Handlebar joint
26 Crown guard (optional - not shown)
27 Crown
28 Crank
29 Right hand pedal
30 Rear disk brake
31 Front hub axle
32 Front disk brake
33 Front suspension fork
34 Electric motor
7. DESCRIPTION OF THE BICYCLE
6. TECHNICAL DATA
7.a - Brakes
- The bicycle is tted with two, independent disk
brakes.
The left hand lever operates the front brake
(g. “9“) and the right hand lever operates the
rear brake (g. “10“).
- Ride with caution until the braking system
running in period has been completed.
- Run the braking system in by carrying out
30 brief braking manoeuvres, coming to a
complete standstill from a medium speed
(approx. 25 km/h).
- Once the braking system has been run in,
the braking force will be noticeably greater.
Operating the brake levers too
sharply may cause the wheels to
lock and expose the rider to the
rider of falling (g. “11“).
35 Left hand pedal
36 Speed sensor
37 Front light
38 Tail light
39 Racks
40 Stand
41 Front mudguard
42 Rear mudguard
43 “Safety recommendation booklet + inspection
forms and shipping documents"
