Checks and inspections
4. TIGHTENING TORQUE
The corresponding tightening torque (in Nm) is
stamped into the heads of the bolts and screws.
If no specic information has been provided by
the manufacturer, refer to the following tightening
torque values.
Threaded joint Thread Tightening torque (Nm)
Pedals 9 / 16” 30
Handlebar joint expansion bolt M8 5
Handlebar joint angle adjustment screw M6 6
Handlebar joint screws M5
M6
M7
5
6
7
Saddle support tube joint
Saddle joint
M8
M6
10
10
Brake M6 8
Brake unit screws M6 8
Gear lever joint M5 5
Brake lever joint M5 5
Hand grips xing screw M4
M5
3
5
Rear wheel pin - 15
Cranks screws M15 50
