Using power assisted pedalling
2. REMOVING THE BATTERY
PACK FROM ITS SUPPORT
- Disconnect the connector from the battery
pack (g. “54“).
- Completely unscrew the battery xing screw
until you remove it (g. “55“).
- Raise the battery pack until you release it from
its support and remove it (g. “56“).
- Place the battery pack on a at and dry surface.
Do not put the battery pack in
contact with water or other liq-
uids. If this happens, do not use
it and let it be checked by the re-
tailer.
3. CHARGE THE BATTERY PACK
3.a - Activating the battery pack
before use
The battery pack is supplied partially charged.
For this reason, it should be tested before recharg-
ing it.
- Press the button (1) to activate the battery.
· The four LEDs light up in sequence.
- Press the button (1), the LEDs light up for ap-
prox. 4 seconds, indicating the battery pack
charge level.
· If none of the LEDs light up it means that the
battery is completely discharged.
· If at least one LED lights up, the battery is at
least partially charged.
- Press the button (1) for 3 seconds to switch the
battery pack o.
Make sure that the battery pack is fully
charged (all four LEDs lit) before you use you
bicycle.
The battery switches o after 10 seconds.
3.b - Charging the battery pack
(g. “57“ and“58“)
Always use the battery charger
supplied with the bicycle.
The battery pack may be recharged at any
moment, without aecting the duration,
however:
In order prolong battery life, it
should not be recharged too often,
or left in the discharged state for
more than two months at a time.
- Connect the power cable to the electrical
mains socket.
Make sure that the electrical mains supply
voltage corresponds to the value indicated
on the battery charger data plate.
- Connect the small plug on the power cable to
the socket on the battery charger (g. “59“).
- Connect the charger connector to the socket
on the battery pack.
- At this point the battery starts to recharge.
- The LEDs on the battery pack light up to in-
dicate the charge level. When all four LEDs
are lit it indicates that the battery pack is fully
charged.
Each LED corresponds to approx. 25% of the
full charge.
-
Disconnect the battery charger from its power
supply and the connector from the battery pack.
- Once the battery pack has been fully charged,
if it remains connected to the battery charger,
and the latter remains connected to its power
- After a certain period of inactivity (approx. one
hour), the assisted pedalling system enters
“SLEEP” mode.
- To restart the system, it is necessary to press
button “T1” on the tool twice (at intervals of
one second).
