CONNECTION OF DRAIN HOSES
Insert the drain hose into a drain pipe with a
minimum diameter of 4cm, or let it run into the
sink, making sure to avoid bending or crimping it.
e free end of the hose must be at a height lower
than 60cm and must not be immersed into water
to avoid the backow of it.
PLEASE HANG UP THE DRAIN
HOSE EITHER WAY OF A, B
NOTE
The top of the hose must be
less than 600 mm.
FRONT
Drain pipe
A
B
40mm
Counter
MAX 600mm
