36
RAC 3000
75036025 - RAC 3000 – rev 09 - ( 12-2021 )
GB
Tab. 1/2
No. CODE Q.ty DESCRIPTION KIT
01 717004 1 Nozzle for rivet ø 4,8 Cu / Steel
02 71346400 1 Sleeve carrying nozzle
03D 711337 1 Gasket OR 2-021 D
04 710562 1 Clamps holding cone
05 71345507 3 High-performance clamp
06 711270 1 Clamps opener
07 710853 1 Spring
08D 711336 3 Gasket OR 2-114 D
09A 71346130 1 Ring A
10 717005 1 Nozzle for rivet ø 6 / 6,4
11 713255 1 Front connector
12D 711722 1 Gasket B-094063-B / NEI D
13D 713272 2 Gasket OR 2-125 D
14D 713278 3 Gasket OR 2-122 D
15D 713277 1 Ring Parbak 8-122 D
16D 713276
1
Gasket TSE-134094 D
17D 713258 1 Anti-extrusion ring D
18 713251 1 Hydraulic piston
19D 713273 2 Gasket OR 17,5 x 1,5 D
20D 713274 2 Gasket OR 8 x 1,5 D
21 713247 1 Bush
22 711821 1 Seeger ring JV 20
23D 713275 1 Gasket OR 2-122 D
24 723269 1 Hydraulic cylinder
25 71346119 1 Balancer hook
26D 710350 1 Gasket OR 2-109 D
27 713250 1 Back connector
28 711273 1 Container connector
29 717007 1 Nozzle for rivet ø 7,8
30 717018 1 Nozzle for rivet ø 4,8
31 717019 1 Nozzle for rivet ø 6,4
32 717015 1 Nozzle for rivet Farbolt ø 6,4
33 717016 1 Nozzle for rivet Farbolt ø 4,8
34 713213 3 Clamp for Farbolt
35 710969 1 Oil container
36 711092 1 Wrench 5 mm
37D 710367 2 Gasket OR 2-008 D
38 711234 3 Pin ø 2 x 11,8
39 72A00163 1 Long valve body
40D 710918 2 Gasket OR 2-005 D
41 711254 1 Valve piston
42D 711338 1 Gasket OR 2-003 D
43 711261 1 Leve for inlet opening
44 710824 1 Push button
45D 710919 1 Gasket OR 2-004 D
46 711253 1 Valve piston
47 711356 1 Cone holding clmaps for Farbolt
48 711370 1 Out put connector
49 710906 1 Washer 400-020-4490
50 710839 1 Oil tank plug
51 71345610 1 Handgrip
52 71345212 1 Nails baffle
53 711059 2 Rilsan tube ø 5 x 3,5 x 2600
54 71345609 1 Ending handgrip connector
55D 71C00697 1 Gasket OR 5-256 D
56 71345607 1
Connector
57 71345606 1
Flanged connector
58 711039 1
Rotating connector
KIT
No. CODE Q.ty DESCRIPTION
KITA 743254 Cone holder kit
KITB 740819 Nail tank kit
KITC 742144 Screw M 3 kit
KITD 74000046 Gaskets kit
03D 711337 1 Gasket OR 2-021
08D 711336 3 Gasket OR 2-114
12D 711722 1 Gasket B-094063-B / NEI
13D 713272 2 Gasket OR 2-125
14D 713278 3 Gasket OR 2-122
15D 713277 1 Ring Parbak 8-122
16D 713276 1 Gasket TSE-134094
17D 713258 1 Anti-extrusion ring
19D 713273 2 Gasket OR 17,5 x 1,5
20D 713274 2 Gasket OR 8 x 1,5
23D 713275 1 Gasket OR 2-122
26D 710350 1 Gasket OR 2-109
37D 710367 2 Gasket OR 2-008
40D 710918 2 Gasket OR 2-005
42D 711338 1 Gasket OR 2-003
45D 710919 1 Gasket OR 2-004
55D 71C00697 1 Gasket OR 5-256
59D 711061 3 Gasket OR 5-614
61D 710921 1 Gasket OR 2-115
KIT
It indicates that the part is sold in kits consisting
of different parts in different quantities.
Tab. 1/2
No. CODE Q.ty DESCRIPTION KIT
59D 711061 3 Gasket OR 5-614 D
60 71345608 1 Fixed connector
61D 710921 1 Gasket OR 2-115 D
62 711036 1 Reduction
63 71C01554 1 High pressure tube mt 1,85
64 71C00729 2 Connector 6580 - ø 5
65 713391 1 Flat key 12 mm
SPARE PARTS
