A.4.2.
Frame Part
Rear Dovetail Connection
Your grain drill has a uniform frame made of ST52
quality steel and designed for use in harsh conditions.
All the components on the frame has rigid form; the
sections such as box part, draw bar part, marker
mechanism, calibration mechanisms, platforms and
coulters are positioned on this frame.
There is a dovetail on the rear side of the frame where
roller and lightweight 4-wheel trailers can be coupled, with
a maximum vertical and horizontal bearing capacity of 200
kg.
The loading platforms must be switched to park position in
order to use the rear dovetail on the frame.
CAUTION!
In the equipment to be coupled with the rear dovetail
on the frame, exceeding the abovementioned weight
of 200 kg leads to damaging of the frame.
Furthermore, this violation constitutes a serious
accident hazard since it will bring the center of gravity
of the machine behind the wheels.
