Faroudja DVP3000 - Specifications

14
DVP3000 / DVP3000U
Inputs (Interlaced)
Composite 1vpp
S-Video Y – 1v pp
C -286mv pp
Component (YCrCb) Y - 1vpp
(Interlaced) Cr – 700mv pp
Cb – 700mv pp
Component (YPrPb) Y - 1vpp
(Progressive) Cr – 700mv pp
Cb – 700mv pp
Computer/HDTV D15M (Progressive or Interlaced)
(Note: Input format must match output format)
Remote Control "D9F" RS-232 ASCII
IR Receiver Tip =+5V, Ring = Signal, Body = Ground
Outputs
Resolution and Scan Rate Specifications: see Appendix A
R,G,B 0.700mv pp, TTL Sync
YPrPb 700mv pp, Sync on Y-1vpp
RGsB G – 1vpp,
RG – 700mv pp
D15F
Horizontal Sync: 4.0 vpp TTL
Vertical Sync: 4.0 vpp TTL
Composite Sync : 4.0 vpp TTL
Custom Presets 20 for DVP3000
16 additional for DVP3000U
12V Screen Trigger Tip = 12V-150mA, Ring = Not Used, Body = Ground
Internal Aspect Ratio Control
16:9 Screen: Anamorphic-Letterbox-4:3
4:3 Screen: Anamorphic-Letterbox-4:3 at scan rates 720p+
Dimensions 17L X 17.25W X 4.24H (with feet)
Weight 19.5lbs, 31lbs shipping
Power Consumption 60w 100-240VAC
50/60Hz Auto Ranging
Specifications
Pin Function
1 Red Output
2 Green Output
3 Blue Output
6 Red Gnd
7 Green Gnd
8 Blue Gnd
10 Sync Gnd
11 Sync Gnd
13 H Sync Output
14 V Sync Output
