Fast Bazooka BT6014 - Mounting the Bazooka

7
1. With the topside of the buckle facing up (see figure 1), lace the strap
through the mounting base as illustrated in figure 2
MOUNTING THE BAZOOKA
2. After the strap is completely laced through the mounting base, make
a loop with the strap, where it runs across the middle of the base as
illustrated in figure 3. This loop is necessary to access the two mounting
holes in the base.
Figure 1
Figure 2
Figure 3
To p
Logo
should
face up
ENGLISH
