3-8
Ramp Function Instructions
FUN
No.
Name Operand
Derivative
instruction
Function descriptions
95 RAMP
Tn,PV,SL,
SU,D
Ascending/Descending convenient instruction
Communication Function Instructions
150 M-Bus MD,S,Pt Modbus protocol communication
151 CLINK MD,S,Pt Fatek/Generic protocol communication
Table Function Instructions
100
R→T
Rs,Td,L,Pr DP Store the Rs value into the location pointed by the Pr in Td
101
T→R
Ts,L,Pr,Rd DP Store the value at the location pointed by the Pr in Ts into Rd
102
T→T
Ts,Td,L,Pr DP
Store the value at the location pointed by the Pr in Ts into the
location pointed by the Pr in Td
103 BT_M Ts,Td,L DP Copy the entire contents of Ts to Td
104 T_SWP Ta,Tb,L DP Swap the entire contents of Ta and Tb
105 R-T_S Rs,Ts,L,Pr DP
Search the table Ts to find the location with data different or equal to
the value of Rs. If found store the position value into the Pr
106 T-T_C Ta,Tb,L,Pr DP
Compare two tables Ta and Tb to search the entry with different or
same value. If found store the position value into the Pr
107 T_FIL Rs,Td,L DP Fill the table Td with Rs
108 T_SHF
IW,Ts,Td,
L,OW
DP
Store the result into Td after shift left or right one entry of table Ts.
The shift out data is send to OW and the shift in data is from IW
109 T_ROT Ts,Td,L DP Store the result into Td after shift left or right one entry of table Ts.
110 QUEUE
IW,QU,L,
Pr,OW
DP Push IW into QUEUE or get the data from the QUEUE to OW (FIFO)
111 STACK
IW,ST,L,
Pr,OW
DP Push IW into STACK or get the data from the STACK to OW (LIFO)
112 BKCMP Rs,Ts,L,D DP
Compare the Rs value with the upper/lower limits of L, constructed
by the table Ts, then store the comparison result of each pair into the
relay designated by D (DRUM)
113 SORT S,D,L DP
Sorting the registers starting from S length L and store the sorted
result to D
Matrix Instructions
120 MAND Ma,Mb,Md,L P Store the results of logic AND operation of Ma and Mb into Md
121 MOR Ma,Mb,Md,L P Store the results of logic OR operation of Ma and Mb into Md
122 MXOR Ma,Mb,Md,L P Store the results of logic Exclusive OR operation of Ma and Mb into Md
123 MXNR Ma,Mb,Md,L P Store the results of logic Exclusive OR operation of Ma and Mb into Md
124 MINV Ms,Md ,L P Store the results of inverse Ms into Md
125 MCMP Ma,Mb,L Pr P
Compare Ma and Mb to find the location with different value, then
store the location into Pr
