INSTALLATION & OPERATION MANUAL
MULTI-FLAVOR MERCHANDISERS
2
1. SAFETY
1.1 Electrical
This accessory must be properly installed according to the instructions in this manual. This will ensure that the accessory
is properly grounded to avoid possible fatal electric shock or serious injury to the operator. Before attempting any internal
maintenance, disconnect electrical power to the dispenser to prevent personal injury. Only qualified personnel should
service internal components or electrical wiring.
1.2 General Precautions
This equipment, depending on the accessory, can weigh up to 18.9 pounds (8.6 kilograms). To avoid personal injury or
equipment damage, do not attempt to lift the merchandiser without help. Working with a partner is highly recommended.
Take care when lifting and positioning the merchandiser to avoid damage and injury.
2. SPECIFICATIONS AND REQUIREMENTS
2.1 General Requirements
The merchandiser is compatible with only the dispenser that corresponds to its merchandiser series, and will not function
properly if installed onto a dispenser outside of the series. The 771 and 772 multi-flavor dispensers belong to the 77x
series and therefore use the same merchandiser model; whereas, a 372 multi-flavor merchandiser should only be installed
on a 372 dispenser.
2.2 Dimension and Weight Specifications
2.3 Touchscreen Specifications
Specication 372 MFLV 771 MFLV 772 MFLV
Width 15.75" (400 mm) 17.0" (432 mm) 17.0" (431 mm)
Depth 2.2" (56 mm) 2.9" (74 mm) 2.9" (74 mm)
Height - Short Door 13.5" (342 mm) 15.6" (396 mm) 15.6" (396 mm)
Height - Tall Door N/A 23.1" (587 mm) 23.1" (587 mm)
Weight - Short Door 8.7 lb (3.9 kg) 12.9 lb (5.9 kg) 12.9 lb (5.9 kg)
Weight - Tall Door N/A 18.9 lb (8.6 kg) 18.9 lb (8.6 kg)
Specication 372 MFLV 771 MFLV 772 MFLV
Flavor & Base Syrup Images 600 x 500 pixels 600 x 500 pixels 600 x 500 pixels
Background Image 800 x 480 pixels 1920 x 1080 pixels 950 x 1080 pixels
