FD smart - DECOMPOSITION CHART

DECOMPOSITION CHART
Tools
Screwdriver
(not included)
See page 5-6 for details.
Attention: Some parts need to assemble in both sides.
Car body*1 Windshield*1
Rear wing*1
Steering wheel*1
Left support of
rear wing*1
Wheel cover*4
Charger*1
Remote
control*1
Wheel*4
Seat*1
M5x35mm
Machine screw*1
Washer*2 (Double-motors version) Washer*3 (single-motor version)
M5 Cap nut*1
Right support of
rear wing* 1
1 2 3 4 5 6 7 8 9 10
11 12
13 14 15
Screw 4x12mm
8mm*2(used to
lock the seat)
7
7
5
8
8
6
7
8
8
11
10
12
12
12
14
7
9
4
3
2
1
Note:Only for Single-motor version.
4
