Featherweight Scooter - 3.0 Specifications; Technical Specifications Overview

6
Never attempt to get onto or off your scooter without first removing the key from the key
switch. This will prevent the scooter from moving if accidental throttle control lever contact
is made.
WARNING!
Never drive the scooter with the tiller lock in the locked position.
3.0 SPECIFICATION
Weight Capacity
265 lbs.
Overall Size
40”x22”x36”（LxWxH）
Size after folding
37.5”x22”x18”（LxWxH）
Front Wheel
6”x2” (plastic hub)
Rear Wheel（mm）
10”x2” (pneumatic tire ,one-piece hub)
MAX Speed
5 mph
Grade Ability
≤8°
Static stability
≥6°
Dynamic Stability
≥6°
Spanning Ability(mm)
≤60
Travel Range (Max)
7.5 Miles
Turning Radius (Min)
5.1 feet
Ground Clearance(mm)
3”
Weight(kg)（exclude battery）
37 lbs.
Brake system
Electromagnetic brake
Driving system
Rear wheel (differential) drive
Controller
PG
Battery
25.2V/10Ah（Lithium）
Motor power（VA）
120W Brushless motor
