20
TO TURN OFF GAS TO APPLIANCE
Fig. 19 - Control Knob Position
THERMOSTAT CONTROL OPERATION
The thermostatic control used on this model differs from standard thermostats. Standard ther-
mostats simply turn the burner on and off. The thermostat used on this heater senses the room
temperature. At times the room may exceed the set temperature. If so, the burner will shut off.
The burner will cycle back on when room temperature drops below the set temperature. The
control knob can be set to any comfort level between HIGH (5) and LOW (1).
Shutting Off Heater
Turn control knob clockwise to the OFF position.
Shutting Off Burner Only (pilot stays lit )
Turn control knob clockwise to the PILOT position.
Ignitor Button Control knob
