Febco 825YA - Model 825 Type D and YD (21;2-10) Parts; Assemblies; Kits: Model 825 D; Assemblies; Kits: Model 825 YD

24
MAINTENANCE MANUAL MODELS 825Y, 825YA, 825, 825D, 825YD & 826YD
Model 825 Type D and YD (2
1
/2–10") Parts
Check Assembly 4–10"
825D and 825YD
Figure No. 15
Cover and Check 2
1
/2–3"
825D and 825YD
Figure No. 16
3
4A
9, 10
7
51
5
11
6
7B
7A
15
4
4A
9, 10
Spring Assembly
Check # 1
905-085 or 905-087
Check #2
905-086 or 905-088
G
Assemblies / Kits: Model 825D
DESCRIPTION
SIZE
2
1
/ 2 "
SIZE
3"
SIZE
4"
SIZE
6"
SIZE
8"
SIZE
10"
Spring As sem bly #1 Check
(3, 4A, 5, 6, 7, 7A, 7B, 10, 1 1, 15, 51)
905-085
905-087 902-466 902-468 902-470 902-472
Spring As sem bly #2 Check
(3, 4A, 5, 6, 7, 7A, 7B, 9, 10, 1 1, 15, 51)
905-086
905-088 902-467 905-469 902-471 905-473
Seat Ring Kit (2, 2A, 2C, 2D, 12)
902-386Y D 902-385Y D 902-384Y D 902-383Y D 902-382Y D 902-381Y D
Rubber Parts , CI & DI Boddi es (1 1, 14, 51)
905-059 905-060 905-061 905-062 905-063 905-064
Large Mounting Ki t (16, 17, 17A, 17B, 40, 41,
Both Ends )
905-036 905-037 905-038 905-039 905-040 905-041
Relief V alve Assy (Type YD Only ) (21 - 50)
905-100 905-100 905-100 905-101 905-101 905-101
Relief V alve Kit - Rubber (26, 27, 27A, 31A, 32)
905-102 905-102 905-102 905-102 905-102 905-102
Relief V alve Seat Ring Kit (22A, 22B, 36, 36A, 36B)
905-103 905-103 905-103 905-103 905-103 905-103
Internal Modular Assem bly - Reli ef V alve Ki t
905-104 905-104 905-104 905-104 905-104 905-104
Assemblies / Kits: Model 825YD
