FEC AFC3000 - 2-1 System Specifications

Ethernet-I/P Fieldbus Expansion Unit
PAGE 27
Enter I/O Description into Tag Table
Input signal of AFC3000 system fixed as shown in the below table.
Name Description Name Description Name Description
O.Data[0].0 Emergency Stop O.Data[4].0 SEQ NO.17 Select O.Data[8].0 Spindle 11 BYPASS
O.Data[0].1 Reset O.Data[4].1 SEQ NO.18 Select O.Data[8].1 Spindle 12 BYPASS
O.Data[0].2 Reverse O.Data[4].2 SEQ NO.19 Select O.Data[8].2 Spindle 13 BYPASS
O.Data[0].3 Start O.Data[4].3 SEQ NO.20 Select O.Data[8].3 Spindle 14 BYPASS
O.Data[0].4 Sequence Select Bit 0 O.Data[4].4 SEQ NO.21 Select O.Data[8].4 Spindle 15 BYPASS
O.Data[0].5 Sequence Select Bit 1 O.Data[4].5 SEQ NO.22 Select O.Data[8].5 Spindle 16 BYPASS
O.Data[0].6 Sequence Select Bit 2 O.Data[4].6 SEQ NO.23 Select O.Data[8].6 Spindle 17 BYPASS
O.Data[0].7 Sequence Select Bit 3 O.Data[4].7 SEQ NO.24 Select O.Data[8].7 Spindle 18 BYPASS
O.Data[1].0 Sequence Select Bit 4 O.Data[5].0 SEQ NO.25 Select O.Data[9].0 Spindle 19 BYPASS
O.Data[1].1 Cycle Count UP O.Data[5].1 SEQ NO.26 Select O.Data[9].1 Spindle 20 BYPASS
O.Data[1].2 Cycle Count Clear O.Data[5].2 SEQ NO.27 Select O.Data[9].2 Spindle 21 BYPASS
O.Data[1].3
Sequence Select
Method
O.Data[5].3 SEQ NO.28 Select O.Data[9].3 Spindle 22 BYPASS
O.Data[1].4 Input Wait Port 1 O.Data[5].4 SEQ NO.29 Select O.Data[9].4 Spindle 23 BYPASS
O.Data[1].5 Input Wait Port 2 O.Data[5].5 SEQ NO.30 Select O.Data[9].5 Spindle 24 BYPASS
O.Data[1].6 Input Wait Port 3 O.Data[5].6 SEQ NO.31 Select O.Data[9].6 Spindle 25 BYPASS
O.Data[1].7 Input Wait Port 4 O.Data[5].7 SEQ NO.32 Select O.Data[9].7 Spindle 26 BYPASS
O.Data[2].0 SEQ NO.1 Select O.Data[6].0 Spindle 1 BYPASS O.Data[10].0 Spindle 27 BYPASS
O.Data[2].1 SEQ NO.2 Select O.Data[6].1 Spindle 2 BYPASS O.Data[10].1 Spindle 28 BYPASS
O.Data[2].2 SEQ NO.3 Select O.Data[6].2 Spindle 3 BYPASS O.Data[10].2 Spindle 29 BYPASS
O.Data[2].3 SEQ NO.4 Select O.Data[6].3 Spindle 4 BYPASS O.Data[10].3 Spindle 30 BYPASS
O.Data[2].4 SEQ NO.5 Select O.Data[6].4 Spindle 5 BYPASS O.Data[10].4 Spindle 31 BYPASS
O.Data[2].5 SEQ NO.6 Select O.Data[6].5 Spindle 6 BYPASS O.Data[10].5 Spindle 32 BYPASS
O.Data[2].6 SEQ NO.7 Select O.Data[6].6 Spindle 7 BYPASS O.Data[10].6
O.Data[2].7 SEQ NO.8 Select O.Data[6].7 Spindle 8 BYPASS O.Data[10].7
O.Data[3].0 SEQ NO.9 Select O.Data[7].0 Spindle 9 BYPASS O.Data[11].0
O.Data[3].1 SEQ NO.10 Select O.Data[7].1 Spindle 10 BYPASS O.Data[11].1
O.Data[3].2 SEQ NO.11 Select O.Data[7].2 ID Data Clear O.Data[11].2 Message Command Request
O.Data[3].3 SEQ NO.12 Select O.Data[7].3 ID Select enable O.Data[11].3 Message Spindle Offset Bit 0
O.Data[3].4 SEQ NO.13 Select O.Data[7].4 O.Data[11].4 Message Spindle Offset Bit 1
O.Data[3].5 SEQ NO.14 Select O.Data[7].5 O.Data[11].5 Message Spindle Offset Bit 2
O.Data[3].6 SEQ NO.15 Select O.Data[7].6 O.Data[11].6 Message Spindle Offset Bit 3
O.Data[3].7 SEQ NO.16 Select O.Data[7].7 O.Data[11].7 Message Spindle Offset Bit 4
