Ethernet-I/P Fieldbus Expansion Unit
PAGE 36
(Example of Axis format selection shown below – this format will be for EACH spindle connected in the
system)
When the system has more than 1 spindle, the data will be mapped as shown below.
rom total fastening status
Data from SPINDLE 1 nutrunner
Data from SPINDLE 2 nutrunner
Data from SPINDLE 3 nutrunner
Data from SPINDLE 4 nutrunner
Data from SPINDLE 5 nutrunner….up to 32 spindles
To Next Page
