Ethernet-I/P Fieldbus Expansion Unit
PAGE 7
I/O Signal Specifications (Ethernet-I/P)
I/O Input/Output Message Input/Output
MASTER Spindle ￫
PLC
PLC ￫ MASTER
Spindle
MASTER Spindle ￫
PLC
PLC ￫ MASTER
Spindle
Maximum
Setting
32bytes (256 points ) 12bytes (96 points ) 2048 word (4096 bytes ) 16 word (32bytes)
Standard
Setting
32bytes (256 points ) 8bytes (64 points ) 2048 word (4096 bytes ) 16 word (32bytes)
●
●●
● AFC3000 Ethernet-I/P System Signal Specifications (PLC ￫
￫￫
￫ MASTER Spindle)
･ Number of MASTER Spindle Input Points 4 words 8 bytes (256 points)
Input signals are factory set and cannot be changed.
Word No.
BIT
Signal
Word No.
BIT
Signal
No.01
0
STOP
No.03
0
SEQ SELECT No.17
1
RESET
1
SEQ SELECT No.18
2
REVERSE
2
SEQ SELECT No.19
3
START
3
SEQ SELECT No
.20
4
SEQ SELECT BIT 0
4
SEQ SELECT No.21
5
SEQ SELECT BIT 1
5
SEQ SELECT No.22
6
SEQ SELECT BIT 2
6
SEQ SELECT No.23
7
SEQ SELECT BIT 3
7
SEQ SELECT No.24
8
SEQ SELECT BIT 4
8
SEQ SELECT No.25
9
CYCLE COUNT UP
9
SEQ SELECT No.
26
10
CYC
LE COUNT CLEAR
10
SEQ SELECT No.
27
11 SEQ SELECT No. ENABLE 11 SEQ SELECT No.28
12
INPORT 1
12
SEQ SELECT No.
29
13
INPORT 2
13
SEQ SELECT No.
30
14
INPORT 3
14
SEQ SELECT No.
31
15
INPORT 4
15
SEQ SELECT No.
32
No.02
0
SEQ SELECT No.1
No.04
0
BYPASS
SPDL
No.1
1
SEQ SELECT No.2
1
BYPASS
SPDL
No.2
2
SEQ SELECT No.3
2
BYPASS
SPDL
No.3
3
SEQ SELECT No.4
3
BYPASS
SPDL
No.4
4
SEQ SELECT No.5
4
BYPASS
SPDL
No.5
5
SEQ SELECT No.6
5
BYPASS
SPDL
No.6
6
SEQ SELECT No.7
6
BYPASS
SPDL
No.7
7
SEQ SELECT No.8
7
BYPASS
SPDL
No.8
8
SEQ SELECT No.9
8
BYPASS
SPDL
No.9
9
SEQ SELECT No.10
9
BYPASS
SPDL
No.10
10
SEQ SELECT No.11
10
ID DATA CLEAR
11
SEQ SELECT No.12
11
ID SELECT ENABLE
12
SEQ SELECT No.13
12
13
SEQ SELECT No
.14
13
14
SEQ SELECT No.15
14
15
SEQ SELECT No.16
15
(Please refer to AFC3000 Operations Manual Section 5-3-2 and 5-3-3 for description of respective
signals)
