Fedders C1018BBD - Page 7

30°F - 16.7°C
25°F - 13.9°C
20°F - 11.1°C
15°F - 8.3°C
10°F - 5.6°C
5°F - 2.8°C
12.8
55
15.6
60
18.3
65
21.1
70
23.9
75
26.7
80
32.2
90
29.4
85
35.0
95
37.8
100
40.5
105
43.3
110
46.1
115
°C
°F
LINE LIMIT – DO NOT ADD CHARGE IF POINT FALLS BELOW THIS LINE.
Chart based on 350 to 400 CFM / ton indoor airflow and 50% relative humidity use
on systems that cool with fixed restrictor.
OUTDOOR TEMPERATURE °F / °C
29.4 C
80°F
26.7°C
75°F
23.9°C
70°F
21.1°C
SUPERHEAT CHARGING CHART FOR UNITS WITH PISTONS
SUBCOOLING CHART FOR UNITS WITH THERMOSTATIC EXPANSION VALVES
7
