Feelworld F970 - Port Instruction (Left)

5
1.1 Button Instruction
Button
Function when OSD is not
displayed
Function when OSD is
displayed
F1
Custom button F1
/
F2
Custom button F2
/
＜
Decrease the volume or
backlight
Decrease or adjust value of
selected parameter
＞
Increase the volume or
backlight
Increase or adjust value of
selected parameter
MENU
Display OSD Main menu
Return to previous OSD menu
∨
/
Select next menu item
∧
/
Select previous menu item
Power On/Off button
1.2 Port Instruction (Bottom)
DC OUT 8.4V: DC power output interface, polarity as the output
power Barrel output for powering your camera with a
separately available DC coupler via adaptor (NP-FW50 Sony &
