FEIERDUN FOR01 - Step 10: Attach Trim Panels and Accessories

43
63
62
42
48
44
72
97
97
105
105
5
38
38
60
60
8
8
-13-
STEP 10˖
1. Attach the Trim Panel (48) to the two Upper Cross Beams (8), using two M8X15mm Bolts
(97) and two M8 Washers (105).
2. Slide the two ￠50 Barbell Spring Clips (60) into two OB Tubes-Long (38).
3. Attach the Chain (63) to the Lower Bar (42), using one Buckle (62).
4. Attach the Lower Bar (42), Handle-Curved (43), Lat Bar (44) and Prissdown Rope (72) to
the Upper Connection Tube (5).
ASSEMBLY INSTRUCTIONS
