felfil evo - Mounting #3: Extrusion Screw to Gearmotor

Complete Kit Manual
12
Tools
Small Parts
Insert the extrusion screw T8 trought the structural support P1 and screw it to the gear-
motor E1 [put the four washers in front between E1 and P1]
Note: insert only screws in the bottom holes.
Mounting #3
4
2X 2X
