felfil evo - Mounting #9: Encoder and Knob Installation

Complete Kit Manual
19
Tools
Small Parts
Fix the encoder E5 on the right lateral side C3, using it’s nut.
Push the knob E6 on the encoder E5.
Insert 4X electric wires in the encoder E5.
Mounting #9
10
4X
C3
E5
E6
