felfil evo - Mounting #11: Switch, Feet, Power Connector

Complete Kit Manual
22
Tools
Small Parts
Insert the switch E7 in the squared holes of C2 (lower case)
Insert the four feet C5 into the holes of C2
Insert the power supply connector E8 into its hole of C2, then screw it using it’s nut and
spring washer
Mounting #11
19
C2
E7
E8
C5
