felfil evo - Connections #4: Gearmotor and Thermocouple Wiring

Complete Kit Manual
28
Connections #5
TK- TK+
GND +12V
Pay attention. Do not invert the gearmotor cables order, or the screw will turn anticlock-
wise.
Pay attention. Do not invert the thermocouple cables order, or the temperature will be
always displayed on 0°C.
!
!
